Surge Lightning Protection -BT P DC 220 RM
Lightning Surge Protection BT P DC 220 RM（811220）is for installation at LPZ 0B-1 or higher, protecting low voltage dc power equipment from surge damage. Applied in modular SPD Class II (Class C) for dc 220V power supply system. Designed according to IEC 61643-11:2011 ; EN 61643-11:2012; GB 18802.1-2011.
-
Type
BT P DC 220 RM
-
Art.-No.
811220
-
Features
1. Pluggable module, easy for installation and maintenance. 2. Surge protection specially designed for use in dc circuits applications. 3. High discharge capacity, quick response. 4. Double thermal disconnector devices, providing more reliable protection. 5. Windows will change red when fault and also provide remote alarm control at the same time.
Inquiry
Download Datasheet
220V DC SPD
In=20kA(8/20μs)，Imax=40kA(8/20μs)
T2 Surge Protector
High Energy MOV + High Energy GDT
35mm DIN Rail，EN 60715
Lightning Surge Protection - BT P DC 220 RM
Lightning Surge Protection - BT P DC 220 RM is a highly effective surge protection device designed for DC-powered systems, providing comprehensive protection against lightning strikes, voltage surges, and other electrical disturbances. This device ensures the safety of sensitive DC equipment, including solar systems, industrial controls, telecommunications, and more, by diverting harmful surges to the ground and maintaining stable operation.
Functions:
- Comprehensive Surge Protection: Specifically designed to protect DC systems operating at 220V DC from lightning strikes, voltage surges, and other electrical disturbances.
- High Surge Capacity: Can handle large surge currents from lightning or other high-voltage events, ensuring that your equipment remains safe even during extreme electrical surges.
- Fast Response Time: Instantly disconnects power to the system when a surge is detected, preventing damage to sensitive equipment. It then automatically resets once the surge is cleared, ensuring continuous protection.
- Efficient Noise Filtering: In addition to surge protection, the device filters out electrical noise, helping to maintain the performance and reliability of your DC systems.
- Rugged and Durable Design: Built with high-quality materials to ensure durability and reliability in various harsh environments, including outdoor and industrial applications
Technical Specifications:
- Voltage Range: Designed for 220V DC systems (specific voltage range may vary depending on model).
- Rated Current: Typically supports up to 20A or higher, depending on the model.
- Surge Capacity: Can withstand high surge currents (e.g., 6000A or more) to protect against lightning strikes and power surges.
- Response Time: Fast response time, instantly disconnecting power when a surge is detected to protect connected equipment.
Advantages:
- Prevents Equipment Damage: Shields valuable DC-powered equipment from lightning and power surges, preventing costly repairs and replacements.
- Improves System Reliability: Ensures stable and uninterrupted operation of DC systems by eliminating the risk of electrical disturbances.
- Cost-Effective Protection: Offers an affordable solution for protecting sensitive equipment, ultimately reducing maintenance costs and improving system longevity.
- Enhanced Safety: Protects against potentially dangerous surges that could pose risks to personnel and equipment.
Technical Data
