Best Surge Protector -BS LCD 24/4M

The Industrial Control Surge Protector BS LD 24(610006) protects unbalanced interfaces that have two single wires using measuring and controlling systems. The 0-20mA 4-20mA control line input/output interface and field bus receive design from lEC 61643-21; EN61643-21; GB 18802.21.

Type

BS LCD 24/4M
Art.-No.

620357
Features

1. For mounting on the 35mm DIN rail. 2. Composed by two parts: the base and the protection module. 3. The signal will not be disconnected when replacing the module. 4. High discharge capacity, low voltage protection level. 5. Minimum space requirements, four signal lines over a width 12mm (2/3 modules).

Inquiry

Download Datasheet

35mm DIN Rail，EN 60715

0-20mA, 4-20mA

Pluggable Design

For 4 signal lines in measuring and control system

High Daicharge Capacity

The Best Surge Protector functions as an ultimate defense system against threats to valuable electronic devices. The device contains state-of-the-art surge suppression technology and meets UL 1449 certification standards to protect from power surges along with overvoltage and overcurrent events. The device provides plenty of power capacity which allows users to run big appliances in addition to powering numerous devices thereby making it perfect for residential and commercial applications.

Best Surge Protector - Ultimate Protection for Your Devices

The Best Surge Protector exists specifically to provide maximum defense for your electronics through the absorption of power surges together with voltage spikes alongside lightning strikes. This surge protector implements advanced surge suppression technology into its design which protects computers and televisions together with routers and gaming consoles located at home or in an office setting.

Key Features:

High Surge Capacity: The high surge capacity in this unit efficiently handles powerful voltage surges, providing complete safety protection.
Multiple Outlets: The unit provides 6 to 12 outlets that can power and defend multiple devices at once.
USB Charging Ports: Built-in USB ports for convenient charging of mobile devices.
Durable Materials: Durability comes from flame-resistant protective casing and strong, enduring materials for reliability.

Best Surge Protector with Lightning Surge Protection

Additional Benefits:

Durable Construction: Flame-resistant housing for enhanced safety and durability.
USB Ports: The device includes integrated USB ports which users can employ to recharge their mobile devices.
Indicator Lights: Simplify the process of observing the protection state and confirming the ground connection.

Best Surge Protector for Lightning Protection

Technical Data

Product Showcase

Start Your Project

We will respond to you within 24 hours after receiving your request email.

3 Years Warranty
Free Customized Design
Welcome OEM and ODM Service
CE RoHS CB KEMA TUV Certificates
Surge Protecetive Device（SPD）Factory
30+ Years Surge Protector SPD Experiences

Type	BS LCD 5/4M	BS LCD 12/4M	BS LCD 24/4M	BS LCD 48/4M	BS LCD 60/4M	BS LCD 180/4M
Art.-No.	620355	620356	620357	620358	620359	620360
Nominal voltage d.c. [U_N]	5V	12V	24V	48V	60V	180V
Rated voltage(max. continuous d.c. voltage) [U_c]	6V	15V	33V	54V	70V	180V
Rated voltage(max. continuous a.c. voltage) [U_c]	4.2V	10.5V	23.2V	38.2V	49.5V	130V
Nominal current [I_L]	1A	0.75A	0.75A	0.75A	1A	1A
Lightning impulse current (10/350μs) (per line)[Iimp]	2.5kA	2.5kA	2.5kA	2.5kA	2.5kA	2.5kA
Lightning impulse current (10/350μs) (total) [Iimp]	10kA	10kA	10kA	10kA	10kA	10kA
Nominal discharge current (8/20μs) (per line) [In]	10kA	10kA	10kA	10kA	10kA	10kA
Nominal discharge current (8/20μs) (total) [In]	20kA	20kA	20kA	20kA	20kA	20kA
Voltage protection level at Iimp (line-line) [Up]	≤ 29V	≤ 50V	≤105V	≤ 160V	≤ 220V	≤ 520V
Voltage protection level at Iimp (line-PG) [Up]	≤ 26V	≤ 37V	≤ 66V	≤ 95V	≤ 125V	≤ 300V
Voltage protection level at 1kV/us (line-line)/(line-PG) [Up]	≤ 18V/ ≤ 9V	≤ 38V/ ≤ 19V	≤ 90V/ ≤ 45V	≤ 140V/ ≤ 70V	≤ 180V/ ≤ 90V	≤ 520V/ ≤ 250V
Transmission range [F]	1.0MHz	2.7MHz	6.8MHz	8.7MHz	9.0MHz	25.0MHz
Series impedance (per line) [R]	1.0Ω	1.8Ω	1.8Ω	1.8Ω	1.0Ω	1.0Ω
Capacitance (line-line) / (line-PG) [C]	≤ 2.7nF/ ≤5.4nF	≤ 1.0nF/ ≤ 2.0nF	≤ 0.5nF/ ≤ 1.0nF	≤ 0.35nF/ ≤ 0.7nF	≤ 0.25nF/ ≤ 0.5nF	≤ 0.12nF/ ≤ 0.24nF
Response time [t_A](line-line) / (line-PG)	≤ 1ns/≤ 1ns	≤ 1ns/≤ 1ns	≤ 1ns/≤ 1ns	≤ 1ns/≤ 1ns	≤ 1ns/≤ 1ns	≤ 25ns/≤ 25ns
Operating temperature range [Tu]	-40°C…+80°C
Cross-sectional area	0.08mm²-4mm² solid / 2.5mm² flexible
Mounting on	35mm DIN rail, EN 60715
Place of installation	Indoor
Enclosure material	Orange thermoplastic, UL94-V0
Test standards	IEC 61643-21; EN 61643.21; GB 18802.21
Certification	CE; RoHS; ISO 9001:2015;REACH
